MTBE Etherification Strong Acid Catalyst
1. MTBE Etherification strong acid catalyst is macroporous styrene series strong acid cation exchange resin;
2. It has suitable pore structure, specific surface area and catalytic activity;
3. In industrial use, it is characterized by good catalytic activity at low temperature, high conversion rate of isobutene, strong selectivity, and no corrosion to equipment.
Product Introduction
MTBE Etherification strong acid catalyst is a macroporous styrene-based strong acid cation exchange resin with suitable pore structure, specific surface area and catalytic activity.
In industrial use, it is characterized by good catalytic activity at low temperature, high conversion rate of isobutene, strong selectivity, and no corrosion to equipment.
MTBE etherification strong acid catalyst is mainly used for the etherification reaction of methanol and isobutylene to prepare methyl tertiary butyl ether (MTBE) as a catalyst.
Physical properties and activity indicators:
| No. | Item. | Numeric Value. |
| 1. | Shape | Gray Spherical Particle |
| 2. | Exchange Capacity, mol{H+}/g | ≥ 5.2 |
| 3. | Moisture, % | 52-53.5 |
| 4. | Wet Apparent Density, g/ml | 0.86 |
| 5. | Wet True Density, g/ml | 1.23 |
| 6. | Particle Size, mm | 0.315-1.55 |
| 7. | Abrasion Ratio, % | ≥ 95 |
| 8. | Average Pore Size, nm | 25-35 |
| 9. | Surface Area, m2/g | 40-70 |
| 10. | Pore Volume, ml/g | 0.20-0.40 |
| 11. | Bulk Density, g/ml | 0.60 |
| 12. | Max Service Temperature, ℃ | 120 |
| 13. | Type | Hydrogen Type |
Recommended operating conditions and application performance:
| Raw Material Carbon Tetraisobutylene Content | 15~45% |
| Reaction Pressure | 0.5-1.0 Mpa |
| Alcohol to Ene Molar Ratio | 1.0~1.2 |
| Temperature Reflex | 30~80 ℃ |
| Space Velocity | 1~5 h-1 |
| Conversion Rate of Isobutylene | Main reactor≥92%, Catalytic distillation tower≥98.5% |
| Selectivity | ≥ 98% |
MTBE etherification strong acid catalyst has a high conversion rate (in the MTBE device with catalytic distillation, the 20-meter-high bale is packed, the isobutylene content is 20%, and the isobutylene content in the remaining C4 is below 0.02%, generally only about 0.08%). Strong performance (the purity of MTBE).
The conversion rate and selectivity of materials during the use of the MTBE etherification strong acid catalyst are directly related to the reaction temperature, reaction pressure, content of etherifiable olefins, and reaction flow of the device.
FAQ:
Does your product have warranty service? How long is the warranty period?
Re: Yes, of course.
We guarantee sufficient technical support and any guarantee services for all catalyst products and technologies we provide. We have a professional team of engineers to conduct regular inspections and data follow-up records when providing solutions, technical services and later use. Make sure that the catalyst is functioning properly with the unit running.
Usually our warranty period is one year after the unit runs smoothly. During this period, if customers need any technical help and support, we will provide unconditional free service.
Until the catalyst is unloaded and needs to be replaced, we will always pay attention to technical support that does not guarantee sufficient efficiency and safety for customers.
Are you a manufactuer or trading company?
Re: We are a professional petrochemical catalyst manufacturer in Zibo, Shandong. There are also some catalyst products that we are only holders of catalyst technology and patents, and the actual production is completed by our designated cooperating OEMs.
We have more than 20 kinds of our own catalyst products and patents.
